High Accuracy Digital Pressure Gauge with SS Body
LEO5
The LEO5 digital manometers combine a range of functions from other KELLER manometers in a water-tight stainless steel housing. They can detect pressure peaks with a measurement interval of ≥ 1 kHz and record all measurements. Current measured values and saved data can be read out via the USB connection. The pressure values can be shown on the extra-large display in a wide range of units of pressure, which are either pre-programmed or configured by the user.
- Maximum accuracy
- Insulated piezoresistive pressure sensor encapsulated
- Robust, watertight stainless steel housing with safety glass front
- Large, backlit LC display
- Integrated rechargeable battery (USB chargeable)
- Free of license costs KELLER software as download
| Pressure Ranges : | -1…1 to 0…1000 bar |
| Accuracy : | ± 0,05 %FS |
| Total Error Band : | ± 0,1 %FS @ 0…50 °C |
| Interfaces : | USB |
| Display : | 5-digit LCD display |
| Special Characteristics: | All-rounder |
| Reading Capacity | 56'000 measuring points |
- High-resolution pressure measurements
- Pressure peak detection with 1 kHz sampling frequency
- Data logger
- Operated via capacitive touch keys
- Bar graph display
- Temperature display
- Min/max display
- Pressure testing
- Calibration
- Laboratory use
- Industrial applications
